Muxlab LongReach 3G-SDI förlängningskit

17 300 kr



500702

Det här förlängningskittet för 3G-SDI gör det möjligt att skicka 3G-SDI signaler upp till 152 meter via en enkel Cat5e/6 kabel i en point-to-point konfiguration.

The LongReach 3G-SDI Extender Kit (model 500702) features LED diagnostics for sync, signal detect and supports transmission of up to 2.97/3.0 Gbps uncompressed, un-encrypted digital video within television facilities and between professional video equipment. Up to 500 ft.

Features
Supports:
SDI-SMPTE 259M-C ( 270Mbps )
HD-SDI-SMPTE 292M ( 1.485/1.001 Gbps )
HD-SDI-SMPTE 424M/425M ( 2.97/ 3.0 Gbps )
LED diagnostics: sync, signal detect
2 year warranty
Up to 500 feet ( 152 meter ) via Cat5e/6 at all resolutions
Cast aluminium enclosure
