QU-12D
QU-12D är en hög presterande DVI distributions förstärkare som följer HDCP direktiven. Denna enheten gör det möjligt att distribuera 1 DVI signal till 2 skärmar.
Varje utgång kan skicka signalen upp emot 15 meter ( 8-bitar ) och bli kedjelänkade upp till 3 gånger.
The QU-12D is a high performance, HDCP compliant, DVI distribution amplifier allowing one DVI input to be distributed to two displays simultaneously. Each of the buffered outputs can run up to 15 meters (8-bit) and can be cascaded up to 3 layers.
Supports PC resolutions : VGA to WUXGA
Supports HDTV resolutions : 480p to 1080p
Can be cascaded up to 3 layers
Each output can run up to 15m/8-bit or 10m/12-bit
The device will read EDID of output 1 and will record it
Outputs:2x DVI-I [2x DVI-D]
PSU: 5V/2.6A
Dimensions: 123mm [W] x 100mm [D] x 30mm [H]
Net Weight: 260g
Gross Weight: 540g
Feature:
HDMI 1.3 and DVI 1.0 compliantSupports PC resolutions : VGA to WUXGA
Supports HDTV resolutions : 480p to 1080p
Can be cascaded up to 3 layers
Each output can run up to 15m/8-bit or 10m/12-bit
The device will read EDID of output 1 and will record it
Specification:
Inputs: 1x DVI-I [1x DVI-D]Outputs:2x DVI-I [2x DVI-D]
PSU: 5V/2.6A
Dimensions: 123mm [W] x 100mm [D] x 30mm [H]
Net Weight: 260g
Gross Weight: 540g
