MA-401
Här har vi en switch med 4 ingångar samt en inbyggd 20W förstärkare för Stereo. Stöd för både ARC och HDR tillsammans med pass-through för ljudformat som LPCM 7.1, Bitstream och HD Bitstream vid 192kHz gör denna till en värdefull enhet vid vissa installationer.
Enheten har även ett sofistikerat system för att hantera IR signaler och genom att registrera varje källas IR-koder och sedan använda sig av switchens fjärrkontroll så kan man styra varje källa direkt.
Det intelligenta IR systemet gör också att bara den utgång som är aktiv får IR signaler skickade till sig, detta gör att man kan ha samma modell av källa på olika ingångar och ändå bara styra den som är aktiv.
The MA-401 is a 4×1 HDMI switcher with a built-in 20w Stereo Amplifier providing high performance audio and video support, including HDR and ARC, making it ideally suited for residential or corporate installations. Up to four high-bandwidth (18Gbps) HDMI sources may be routed to the local HDMI output with support for automatic input switching. Pass-through of multiple digital audio formats such as LPCM 7.1, Bitstream and advanced HD Bitstream with audio sampling rates up to 192kHz are supported at the HDMI output.
This unit also contains a specialized IR learning and smart-routing functionality. IR codes from each of the connected sources' remotes can be learned and then recalled using this unit’s dedicated remote control, or the iOS / Android mobile device app. Intelligent IR routing ensures that only the IR signals appropriate to the source being viewed are used by the dedicated remote control while the mobile device app provides the ability to send IR commands to control any connected source and the TV itself. IR command sets may also be uploaded or downloaded to/from the unit via XML files.
This unit can be controlled in a wide variety of different ways including front panel buttons, RS-232, IR remote, Telnet, WebGUI.
Features:
- Supports up-to 4K UHD (18Gbps, 4K @50/60Hz 4:4:4 8-bit) video input / output
- Supports 10-bit and 12-bit HDR (High Dynamic Range)
- Supports output resolutions up to 4K @50/60Hz (4:4:4 8-bit)
- Supports CEC Bypass
- Supports pass-through of HD audio formats: LPCM 2/5.1/7.1CH, Dolby Digital 2/5.1CH, Dolby Digital Plus, Dolby TrueHD, Dolby Atmos and DTS-HD Master Audio
- CYP Control APP
- IR Learning and remote control programming
- 20w D Class Stereo Power Amplifier
- 3.5mm Analogue audio Line Level Output
Specifications:
| Inputs | 4x HDMI [4x HDMI Uncompressed AV and Data] 1x RJ45 [1x LAN IR Propriety Data] 1x 9pin Dsub [1x RS-232 Data] |
| Outputs | 1x HDMI [1x HDMI Uncompressed AV and Data] 5x 3.5mm Stereo mini-jack [5x Infra Red Emitter] 1x 3.5mm Stereo mini-jack [1x Stereo(L/R)] 4x Phoenix (2 pin) [2x Phoenix Speaker Level Stereo Output] |
| PSU: | 24V/2.7A |
| Dimensions | 219mm [W] x 156mm [D] x 43mm [H] |
| Net Weight | 1172g |
| Gross Weight | 2200g |
