OR-32USBC-4K22
Här har du en matris växel med 3 ingångar, 2 HDMI + 1 USB-C, samt 2 HDMI utgångar.
Enheten är HDCP 2.2 kompatibel och klarar upplösningar upp till och med 4K@60Hz( 4:4:4, 8 bit ) där HDMI utgång A har möjlighet att skala ner upplösningen till 1080p vid behov.
USB-C ingången följer USB 3.0 standarden och stödjer där med A/V, nätverk samt strömförsörjning av andra enheter.
Som bonus har matrisen även en USB 3.0 hub vilket gör den lämplig till t.ex mötesrum, klassrum eller ljud integrering med USB. Enheten kan styras genom frontpanelen, WebGUI:t, Telnet eller över RS-232.
The OR-32USBC-4K22 matrix switch is designed for use in environments needing a wide range of flexibility when it comes to inputs, outputs, and control. The two most common video input interfaces (HDMI, USB-C) are included along with a pair of HDMI outputs, providing the ultimate in source compatibility and flexibility. This unit is HDCP 2.2 compliant and supports resolutions up to a maximum of 4K@60Hz (4:4:4, 8-bit) and HDMI output A supports 4K downscaling to 1080p. The included USB-C input runs on the USB3.0 specs and supports AV, device charging as well as network connection.
This matrix also includes a USB 3.0 hub with two host ports (Type-B and Type-C), plus two device ports (Type-A) for a flexible KVM configuration. It is ideal for use in meeting rooms, classrooms, and audio integration with USB expansion. This unit is controllable via front panel controls, WebGUI, Telnet and RS-232.
Features:
- 2 x HDMI and 1 USB-C 4K60Hz 4:4:4 inputs
- 2 x Matrixed HDMI output with output A supporting 4K downscaling to 1080p
- USB-C port supports USB 3.0 speed, device powering 20V/3A and one gigabit Ethernet at best
- Supports pass-through of 8 channel LPCM, bitstream & HD bitstream audio formats
- Supports 4K HDR formats by HDR10, HLG and Dolby Vision
- Support USB 3.0 with one USB type B and one USB type C interface for connection to a host PC, plus two USB type A ports for peripheral devices such as keyboard, mouse and storage extension
- Supports auto-switch functionality with a “last memory” feature for both input ports and USB ports
- Supports basic signal event automation (via RS-232, IP or CEC)
Specification:
| Inputs | 1x USB-C [1x USB-C / Thunderbolt] 2x HDMI [2x HDMI Uncompressed AV and Data] 2x USB Type A [2x USB Propriety Data] 1x Phoenix (4 pin) [1x RS-232 local control] 1x RJ45 [1x LAN Serving] |
| Outputs | 2x HDMI [2x HDMI Uncompressed AV and Data] 1x USB 3 Type B [1x Power & Data] 1x 3.5mm Stereo mini-jack [1x Analogue Stereo(L/R)] 1x Phoenix (4 pin) [1x RS-232 local output] |
| PSU: | 24V/5A |
| Dimensions | 231mm [W] x 108mm [D] x 25mm [H] |
| Net Weight | 750g |
| Gross Weight | 1670g |
